Heavy Duty Stainless Steel Chain Plate Conveyor for Industrial Automation and Smooth Material Handling

Name: Heavy Duty Stainless Steel Chain Plate Conveyor for Industrial Automation and Smooth Material Handling
Rating: 5.0 (50 reviews)

Request a free quote today and discover how our precision-engineered chain plate conveyor can optimize your production line efficiency!

 

Product Parameters

General Specifications

Product Name:	Chain Plate Conveyor
Material Construction:	Stainless Steel (SS304/SS316), Carbon Steel, Engineering Plastics
Transport Surface Type:	Flat and Smooth
Maximum Load Capacity:	Up to 500 kg/m
Conveyor Speed Range:	0.05 – 2.0 m/s
Incline Angle Capability:	Up to 30° (standard), custom options available
Curve Radius (Minimum):	1.5 m (standard), customizable
Power Supply:	AC 380V / 50Hz or as per regional standards
Motor Power:	0.37 – 7.5 kW (depending on conveyor length and load)
Control System:	PLC-based with variable frequency drive (VFD) for speed control
Cleaning Method:	Direct water washing (IP67 rated components)
Certifications:	CE, ISO 9001, ISO 14001, and food-grade compliance (for SS304/SS316 variants)

Performance Characteristics

Synchronization Accuracy:	±1 mm per meter of travel
Noise Level:	≤ 65 dB(A) at operating speed
Maintenance Interval:	Every 6 months (based on continuous operation)
Dust and Water Protection:	IP65 standard for electrical components
Service Life:	Over 10 years with regular maintenance
Integration Compatibility:	Compatible with industrial automation systems (e.g., SCADA, MES)

Design Features

Modular Design:	Standardized sections for easy assembly and expansion
Customization Options:	Custom lengths, widths, inclines, and belt materials
Surface Finish:	Smooth, non-porous surface for hygienic applications
Chain Type:	Roller chain with anti-corrosion coating or stainless steel chain
Safety Features:	Emergency stop, guardrails, overload protection

Product Details

Product Introduction

The Chain Plate Conveyor from ZhengZhou TianQi Machinery Co., Ltd. is a high-performance solution designed for demanding industrial environments across power, metallurgy, brewing, chemical, medical, and machinery sectors. Built with durable materials like carbon steel, stainless steel, or engineering plastics, it ensures minimal friction, stable synchronized movement, and easy cleaning—ideal for hygienic applications such as food and beverage processing. With options for horizontal, inclined, and curved conveyance, this system adapts seamlessly to complex production layouts. Engineered for reliability, it supports heavy loads and withstands direct water washing while maintaining long-term operational stability. Backed by TianQi’s 98% on-time delivery rate and 2-hour technical response, this conveyor delivers consistent performance for global clients seeking efficient, customized material handling solutions.

Advantages and features

1. Constructed from premium stainless steel or carbon steel for corrosion resistance and long service life in harsh environments.
2. Supports multi-directional transport (horizontal, inclined, curved) for flexible integration into existing production lines.
3. Designed for easy maintenance and direct water washing—meets strict hygiene standards in food, pharmaceutical, and medical industries.
4. Customizable configurations available to match unique production requirements.
5. High load capacity and smooth operation ensure reliable performance in automated manufacturing systems.

Application Scenario

Ideal for food & beverage processing, chemical plants, metal fabrication, pharmaceutical facilities, and general industrial automation lines where durability, cleanliness, and precise material handling are critical. Suitable for manufacturers, OEMs, and integrators worldwide seeking robust, scalable conveying solutions.

Common problem

Q： In which industrial sectors are chain conveyors suitable? Can they withstand harsh environments?

A： Widely used in power, metallurgy, chemical, pharmaceutical, and machinery industries, it is especially suitable for harsh environments such as high temperature, high humidity, and strong corrosion. Made of stainless steel with an IP65/IP67 protection rating, it boasts excellent durability and anti-fouling capabilities, ensuring long-term stable operation of the equipment.

Q： How can the load capacity and operational stability of a chain conveyor be guaranteed?

A： The product has a maximum load capacity of 500 kg/m, adopts a high-strength carbon steel or stainless steel chain plate structure, and is equipped with a variable frequency drive (VFD) system. It operates smoothly and the speed is adjustable (0.05–2.0 m/s). The synchronization accuracy is ±1 mm/m, the noise is ≤65 dB(A), and it is reliable in long-term operation, making it suitable for heavy-duty continuous operation scenarios.

Q： Does this chain conveyor support customized configurations? How can it meet the needs of different production lines?

A： Yes, we offer comprehensive customization services, including length, width, tilt angle, chain type, materials, and control systems (such as PLC or VFD). We can flexibly adjust to the customer's production line layout to achieve seamless integration, ensuring efficient and stable operation and truly matching personalized industrial automation needs.

Q： What are the unique advantages of chain conveyors in the food and beverage industry?

A： Zhengzhou Tianqi Machinery's chain conveyor is made of SS304/SS316 stainless steel, meeting food-grade certification standards. Its smooth, non-porous surface allows for direct washing (IP67 protection), and it complies with GMP and hygiene standards. Its modular design facilitates cleaning and maintenance, ensuring a clean and safe production environment, making it an ideal choice for food and beverage processing lines.
